CSN-S2 Smart Handheld PDA Android POS Terminal

Performance Parameters

CPU

Octa-core 2.0GHz

OS

Android 11.0

Memory

2GB RAM+16GB ROM/3GB RAM+32GB ROM（optional）/4GB RAM+32GB ROM（optional）

SIM Card Slot

2 x Nano SIM Card

Expansion Storage

1 x MicroSD Card（SDHC、SDXC supported，up to 512GB）

Physical Parameters

Display

4" WVGA IPS, 480 x 800, Capacitive Multi-Touch, Glove mode support

Battery

Removable Lithium Battery, 3.85V/5100mAh

Dimensions(L*W*H)

160mm×66.8 mm×16.8mm

Weight

245 g(with battery)

Ports

1×Waterproof Type C ( support USB 2.0, OTG, Fast charging)

Expansion Ports

Back POGO PIN: Trigger handle

Bottom POGO PIN: USB 2.0, 5V/2A

Buttons

Side: 1×Power(lock screen) button, 1×custom button, 2 scan buttons

Front: 26×physical buttons( (including 2 FN buttons)

Prompts

Vibration reminder/Multi-Color LED reminder/audio reminder

Audio

Built-in Speaker (1.5W), Receiver, Dual Microphones (noise reduction)

Sensor

G-Sensor(optional), Light Sensor(optional) ,Proximity Sensor(optional),Gyroscope(optional), E-compass (optional)

Environment Parameters

Working Temperature

-20℃ ～+60℃

Storage Temperature

-40℃ ~ +70℃

Humidity

5% ~ 95%RH(No condensation)

Protection

IP68

Drop Specification

1.8m

Roller Drop

1000 times of roller drops from a height of 0.5 meters (equivalent to 2000 impacts)

Electrostatic Protection

±15 kV air discharge, ±8 kV direct discharge

Data Collection

2D Scanning (optional)

1D and 2D Barcodes Reader

Image Capture

Rear camera: 13/5 Megapixels, flash support, auto focus

Front camera (optional): 5 Megapixels, Fixed Focus

GPS

GPS/Glonass/Beidou, support AGPS

RFID-HF (optional)

Support ISO15693, ISO14443A/B, Mifare card, Felica card,

Support NFC

Support card reader, Point-to-point, Card simulation

Wireless Data Communication

WWAN

Eurasian and American Versions

Wi-Fi

IEEE 802.11 ac/a/b/g/n/ax ready/d/e/h/i/j/k/r/v/w

2.4G/5G Dual-band Wi-Fi，Support fast roaming

Bluetooth

BT5.0 + BR/EDR + BLE

Accessories

Standard

Power Adaptor×1, USB Cable×1, Battery×1

Option

Hand strap, Cradle, Four-slot battery charger, Trigger handle, Fast charging adapter
